parameters

Maximum pipe capacity

Φ115*8t

Minimum bend radius

R30(MM)【Pipe, as set】

Maximum bend radius

R500（mm)

The largest bending angle

185°

Bending speed

50°/sec

Each tube can be set a few bends

2/9

Maximum core length dress

4200（mm)

Control power

AC  220V  【AC contactor】

DC  24V  【Electromagnet】

DC  24V  【Proximity Switches】

Motor Power

22KW

Oil Pump

PVD-17

Flow

29ML/R

System pressure

14MPA

Tank volume

120L

Machine shape

5800*1500*1300（mm）

Machine Weight

10000KG
